Use of cemented material as pavement base or sub-base

 Abstract: Various ingredients materials and various mix design procedures for cemented/stabilized layer in the pavement structure has been reviewed and two types of mixes are considered in the present study viz,

• FLWSRE mix (fly-ash + lime + water + sodium chloride + Recron 3S fibers + emulsion) and
• SCW mix (soil + cement + water).

The optimal proportion of the ingredients of the mix is obtained as, 33 % water, 11 % lime, 0.30 % 12 mm Recron 3S c fibers, 1 % sodium chloride, and 1.3 % bitumen (i.e. 2 % emulsion) for FLWSRE mix by performing UCS test and it is 6 % cement and 14 % water for SCW mix. CBR test is performed to check the suitability of the mix as a pavement material, and result of soaked and unsoaked CBR test indicates that the proposed proportion of the ingredients can be used as pavement base and sub-base layer.

The elastic modulus and fatigue life of the SCW mix is evaluated by performing fatigue test on the SCW mix. Fatigue curve is developed for SCW mix and attempt has been made to explain cemented pavement design procedure with an example. From fatigue life Vs strain plot, design of bituminous pavement with cemented base is performed and compared with conventional design of bituminous pavement with granular base. It has been observed that the life of former is more than that of later configuration. Hence bituminous pavement with cemented base is economical than bituminous pavement with granular base

Acknowledgements

It is my great pleasure to acknowledge those whose active help and support make this thesis possible in the present form. First of all I express my sincerest gratitude to my thesis supervisor Dr. Animesh Das, who introduced me to the fascinating field of Pavement Engineering. It is his endless guidance and constant encouragement,  which ultimately made this thesis submission possible today. I find it really very difficult to express my deep feeling of appreciation about him only in these few sentences. I shall remain indebted to him.


I am also thankful to Prof. Partha Chakroborty and Prof. P.K. Basudhar for giving me insight into the field of Transportation Engineering and Geotechnical Engineering respectively. I am thankful to Transportation Engineering laboratory staff Mr. A. Pugazhenthi and Mr. Manoj Kumar for their help during the experimental setup and testing. Thanks to Reliance Industries Limited for providing Recron 3S fibers, free of cost. I am thankful to Dr. Amit Prashant, Prof. in-Charge, Geotechnical Engineering laboratory for allowing me to conduct the UCS test and CBR test in Geotechnical Engineering laboratory. A very special thanks to Mr. Sant Kumar for his sincere work, without witch I could not have completed my experiments in time. Thanks to my friends Abhishek, Anil, Amit, Ashok, Pushan, Pramod, Ravi, Priyanka, Rami and Teja for their support and co-operation.

Last, but not least, I wish to express my gratitude towards my parents- Shivaji and Rohini, my grandparents- Rangnath and Sitabai, my uncle Raosaheb and aunty Radhika who sacrificed a lot to give me a good education.

-Pravin Kolhe

Conclusion

1. The optimal proportion of the ingredients of FLWSRE mix is obtained as, 33 % water, 11 % lime, 0.30 % 12 mm fibers, 1 % sodium chloride, and 1.3 % bitumen which gives maximum UCS of the order of 390 kPa.
2. The optimum proportions of ingredients of SCW mix is obtained as 6 % cement content and 14 % water content which gives the maximum UCS of order of 1.388 MPa.
3. The unsoaked and soaked CBR of FLWSRE mix is obtained 23.26 % and 18.96 % respectively.
4. The unsoaked and soaked CBR of SCW mix is obtained 86.16 % and 73.31 % respectively.
5. From UCS, CBR and fatigue test results on SCW mix, following relationship can be developed for elastic modulus. E = 0.928 × CBR and E = 57.64 × UCS
6. From fatigue tests on SCW mix, elastic modulus of mix is obtained. From fatigue life Vs strain plot, design of bituminous pavement with cemented base is performed and compared with conventional design of bituminous pavement with granular base. It has been observed that the life of former is more than that of later configuration. Hence bituminous pavement with cemented base is economical than bituminous pavement with granular base.

Future scope

This section gives some of the works that can be taken as further study

1. Various combinations of the materials, like recycled aggregates, poor quality aggregates etc. can be tried and the mix which gives maximum fatigue life can be obtained.

2. Most economical combination of the layer thickness and material properties can be obtained by performing economical analysis.

3. Durability test can be performed to ensure about the performance of stabilized layer.

4. Rutting equation can be developed for bituminous pavement with cemented base.

Bibliography

[1] AASHTO guide for design of pavement structures, American Association of State Highway Officials, Washington, D.C., 1993.
[2] American Standard Test Method (ASTM) (2001). ”Standard specification for coal fly-ash and raw or calcined natural pozzolan for use in concrete.” ASTM C618 - 03, Philadelphia.
[3] American Standard Test Method (ASTM). ”Standard test method for unconfined compressive strength of cohesive soil.” ASTM D2166, Philadelphia.
[4] ASTM D 2487 (2006) Standard practice for classification of soils for engineering purposes (Unified Soil Classification System), American Society for Testing of Materials, West Conshohocken.
[5] Chakroborty., P. and Das., A. Principles of Transportation Engineering, Prentice- Hall of India Private Limited., New Delhi, 2003.
[6] Chemical Soil Stabilization, Compendium 8, Transportation Research Board, National Academy of Science, Washington, D.C., 1979.
[7] Christensen, A.P., Cement modification of clay soils, RD002, Portland Cement Association, Skokie, 1969.
[8] Christian, B., Designing of pavement in Africa with a sand base bound with ground blast furnace slag, Road Research Forum, Pretoria, May 2002
[9] Currin, D.D., Allen, J.J., and Little, D.N., (1976). Validation of soil stabilization index system with manual development, Report No. FJSRL-TR-76-0006, Frank J. Seiler Research Laboratory, United States Air Force Academy, Colorado.
[10] Das, A., and Pandey, B. B., Bituminous pavement with cemented base, Highway Research Board Bulletin, No. 58, IRC, New Delhi, June 1998, pp.77-94.
[11] Draft TRH 4, Structural design of flexible pavements for interurban and rural roads, 1996, Draft TRH4, TRANSPORTEK, CSIR, Pretoria, South Africa, 1996.
[12] Draft TRH 13, Cementitious stabilization in road construction, 1986, Draft TRH13, TRANSPORTEK, CSIR, Pretoria, South Africa, 1986.
[13] Ghosh, P., ”Development of alternative gradation and modification of mix design approach for bituminous concrete (BC) from fatigue life consideration”, MTech thesis, Department of Civil Engineering, Indian Institute of Technology, Kanpur, 2002.
[14] Gray, D.H., and Ohashi. H., Admixtures stabilization of sands with discrete, randomly distributed fibers, Proceeding of 12th International Conference on Soil Mechanics and Foundation Engineering, Brazil, pp. 1363-1366, 1983.
[15] Guidelines for Design of Flexible Pavements, IRC: 37-2001, The Indian Road Congress, New Delhi, 2001.
[16] Gunti, E., (2004). Some studies on the stabilization of Panki pond ash with chemicals and randomly oriented fibers and its strength characteristics. MTech thesis, Department of Civil Engineering, Indian Institute of Technology Kanpur, India.
[17] Kenneth, L., Iowa thickness design guide for low volume roads using recliamed hydrated class C fly-ash bases, Transportation Conference Proceedings, 1998.
[18] Maher., M.H. and Gray., D.H., Static response of sand reinforced with randomly distributed fibers, Journal of Geotechnical Engineering, Vol. 116, No. 11, pp. 1661-1667, 1990.
[19] Material Testing, U.S. Department of Air Force, Manual AFM 88-51, Feb. 1966.
[20] Materials and Tests Division, Design Procedures for Soil Modification or Stabilization, Indiana, Oct 2002.
[21] Method for testing tar and bituminous materials: Determination of water content, IS:1211-1978.
[22] Mitchell, J.K., and Monosmith, C.L., A thickness design procedure for pavements with cement stabilized bases and thin asphalt surfacing, Proceeding of the 4th International Conference of Structural Design of Asphalt Pavements, Vol. I, 1977, pp. 409-416.
[23] Mohammad, J., and Mohammad, A., Durability and mechanistic characteristics of fiber reinforced soil-cement mixtures, The International Journal of Pavement Engineering, Vol. 7, No. 1, 2006, 53-62.
[24] Narendra, B.S., Sivapullaiah, P.V., and Ramesh, H.N., Optimum lime content of fly-ash with salt, Ground Improvement, 2003, No. 7, pp 187-191.
[25] Nataraj, M.S., and McManis, K.L., Strength and deformation properties of soils reinforced with fibrillated fibers, Geosynthetics International, Vol. 4, No. 1, pp.- 65-79, 1997.
[26] Oglesby, C.H., and Hewes, L.I., Highway Engineering, John Wiley and Sons, New York, 1963.
[27] Otte, E., Savage, P.F., and Monosmith, C.L., Structural design of cemented pavement layers, Transportation Engineering Journal, ASCE, Vol.1-108, TE4, 1982, pp. 428-446.
[28] Otte., E. Structural design of cemented pavement layers, ASCE, 108, No.04, 1982
[29] Pavement design, Austroads, Sydney, 1992
[30] Petry., M. T. and Little., D.N. Review of stabilization of clays and expansive soils in pavements and lightly loaded structureshistory, practice, and future, Journal of Materials in Civil Engineering, ASCE, Vol. 14, No. 6, 2002. pp. 447-460.
[31] Ramesh, H.N., Sivamohan, M., and Sivapullaiah,P.V., Improvement of strength of fly-ash with lime and sodium salts, Ground Improvement, No.3, pp. 163-167., 1999.
[32] Ramzi, T., Ali, Al-H, Khalid., Al-S., and Muamer, Al-Z., Cement stabilization of reclaimed asphalt pavement aggregate for road bases and sub-bases, Journal of Materials in Civil Engineering, ASCE, Vol. 14, No. 3, 1, 2002.
[33] Recommended design criteria for the use of cement modified soil for the road construction, 1st reprint, IRC: 50-1973, The Indian Road Congress, New Delhi, 1978.
[34] Robnett, Q., and Thompson, M., Stabilization of Illinois Material - development of guidelines and criteria, Illinois Cooperative Highway Research Program, Project IHR-94, Sept. 1969.
[35] Singh, D. N., Engineering properties of compacted fly-ash, M.Tech. thesis, Department of Civil Engineering, Indian Institute of Technology Kanpur, India.
[36] Singh., G. and Baffour, K.A., Rational design of lime stabilized laterite roads, Transportation Engineering Journal, Proceedings of ASCE, Vol. 107, TE6, 1981.
[37] Sivapullaiah, P.V., Narendra, B.S., and Ramesh, .N., (2003), Optimum lime content of fly-ash with salt, Ground Improvement, No. 7, pp. 187-191.
[38] Chakraborty, T.K., and Dasgupta, S.P., Randomly reinforced fly-ash as foundation material, Indian Geotechnical Conference, Dec 7-11, 1996.
[39] Tentative guidelines for lean-cement concrete and lean cement-fly-ash concrete as pavement base and sub-base, IRC: 74-1979, The Indian Road Congress, New Delhi, 1979.
[40] Tentative Guidelines for use of low grade aggregates and soil aggregate mixtures in road pavement construction, IRC: 63-1976, The Indian Road Congress, New Delhi, 1976.
[41] Theyse, H.L., Beer, M.de., and Rust, F.C., Overview of the South African mechanistic pavement design analysis method, Divisional paper No. DP-96/005,TRANSPORTEK, CSIR, Pretoria, 1996, pp 1-43.
[42] Traffic Census on Non-Urban Roads, First Revision, IRC:9-1972, The Indian Road Congress, New Delhi, 1972.
[43] Wayne, S. Adaska., and David, R. Luhr., Control of Reflective Cracking in Cement Stabilized Pavements, 5th International RILEM Conference, Limoges, France, May 2004.
[44] William, P. G., Charles, A. W., and Raymond, S. R., Stabilized base courses for advanced pavement design report 1: literature review and field performance data, U.S. Department of Transportation, Sept. 1999.
